If the concentration gradient is high, then the diffusion current density is also high. Similarly, if the concentration gradient is low, then the diffusion current density is also low. The concentration gradient for n-type semiconductor is given by. The concentration gradient for p-type semiconductor is given by. Where D n is the diffusion coefficent of electrons. The diffusion current density due to holes is given by. The total current density due to electrons is the sum of drift and diffusion currents. The total current density due to holes is the sum of drift and diffusion currents.

Where D p is the diffusion coefficent of holes. The mean free path is the average length a carrier will travel between collisions. These three averages are related by:. Shown is a variable carrier density, n x. Where the flux due to carriers moving from right to left is subtracted from the flux due to carriers moving from left to right. We now replace the product of the thermal velocity, v th , and the mean free path, l , by a single parameter, namely the diffusion constant, D n , so that:.

We now further explore the relation between the diffusion constant and the mobility. At first, it seems that there should be no relation between the two since the driving force is distinctly different: diffusion is caused by thermal energy while an externally applied field causes drift.

However one essential parameter in the analysis, namely the collision time, t c , should be independent of what causes the carrier motion. Applied to a one-dimensional situation, this leads to:. We use equations 2. Using the definition of the diffusion constant we then obtain the following expressions which are often referred to as the Einstein relations:.

The hole diffusion current density equals:. The total electron current is obtained by adding the current due to diffusion to the drift current, resulting in:. The total current is the sum of the electron and hole current densities multiplied with the area, A , perpendicular to the direction of the carrier flow:.
